IIGMAN
|  |
 |
Micro Catheter for abdomen with a silicone balloon is a 2 way micro catheter that provides temporary occlusion. This corresponds to multipurpose operative technique since the inside diameter of the main lumen is secured.
Specifications
Cello Balloon Guide Catheter Ordering Information
| Reference No. | Length of theTip part | Balloon length | Total length | I.D. (mm) | Shaft diameter |
|---|---|---|---|---|---|
| N5212431 | 15 mm | 10 mm | 1500 mm | 0.4 mm (0.015") |
0.93/1.13 mm (2.8F/3.4F) |
| N5222431 | 8 mm | ||||
| N5232431 | 2 mm | ||||
| N5213431 | 15 mm | 10 mm | 0.5 mm (0.021") |
1.10/1.30 mm (3.3F/3.9F) |
|
| N5223431 | 8 mm | ||||
| N5233431 | 2 mm |
| Comformable maximum guide wire diameter |
Comformable minimum guide Catheter I.D. |
injection amount/diameter (recomendation) |
injection amount/diameter (maximum) |
Anti-pressure of main lumen |
|---|---|---|---|---|
| 0.3mm (0.012") | 1.3mm (0.05") | 0.06mL / 4.0mm | 0.12mL / 5.5mm | 2.07Mpa (300PSI) |
| 0.46mm (0.018") | 1.6mm (0.063") | 0.10mL / 6.0mm | 0.15mL / 7.0mm |
